Floor Plan Examples
These floor plan examples show real layouts drawn to scale and explain what makes each one work. Every plan opens in the editor as your own copy, so you can change it to fit your space.
In this section
- House Floor Plan ExamplesThree house floor plan examples, from 133.9 m² (1441 sq ft) on one level to a 216.0 m² (2325 sq ft) villa on two floors, each annotated and editable.
- Small House Floor Plan ExamplesThree small house floor plan examples under 80.0 m² (861 sq ft): a studio, an open-plan one-bedroom and a one-bedroom with a hallway, annotated.
- Modern Floor Plan ExamplesModern floor plan examples: a two-floor house with wide openings, an open-plan apartment and a flat with a balcony, each annotated and ready to edit.
- Apartment Floor Plan ExamplesApartment floor plan examples compared side by side, from a 39.0 m² (420 sq ft) studio to four bedrooms, with notes on how the layout grows.
- Office Floor Plan ExamplesOffice floor plan examples: a 140.0 m² (1507 sq ft) office with open workspace, plus a private office and a meeting room for six that open furnished.
- Bedroom Layout ExamplesThree bedroom layout examples, a double, a single with a desk and a main bedroom with a storage wall, with sizes in meters and feet. Open each one furnished.
- Kitchen Layout ExamplesFour kitchen layout examples, one-wall, galley, L-shaped with a table and U-shaped, with sizes and aisle widths in meters and feet. Open each furnished.
Whole homes and single rooms
The house, apartment and office examples come from the editor's templates and are drawn from the templates themselves, floor by floor. The bedroom and kitchen examples are single rooms with their furniture placed to size; they open furnished in meters or in feet and inches.
The notes give the sizes and the space left around the furniture in both unit systems. The notes call a clearance a rule of thumb when that is all it is.
Modern 2 Bedroom Apartment
Things to try in the sample
Switch to split view
See the 2D plan and the 3D model side by side.
Select a wall
Change its length, thickness or height in the properties panel and watch the rooms update.
Open the area schedule
See each room's area and the total for the apartment.
Walk through
Enter walk mode in 3D and move from room to room with W, A, S and D.
More starting points
Frequently asked questions
How is an example different from a template?
A template is a starting project you open and change. An example page explains one or more plans: why the rooms sit where they do and how much space the furniture leaves. The whole-home examples are drawn from the templates; the bedroom and kitchen layouts exist only as examples.
Can I use an example as the start of my own plan?
Yes. Every example opens as a new project in your browser. Change it as much as you like; the example itself stays as it is.
Why are sizes measured to the wall center lines?
That is how the editor measures rooms, so the numbers on these pages match the area schedule when you open a plan.
Are the clearances in the notes rules I have to follow?
No. They are rules of thumb for comfortable use. Rules for stairs, bathrooms or bedroom windows are set locally, so check the requirements where you build.
Ready to plan your space?
It is free, runs in your browser and needs no account. Projects are saved privately on this device.
