L-Shaped House Floor Plan Template
An L-shaped house of 134.6 m² (1449 sq ft): the living and dining run along the back, a bedroom wing on the left, and the kitchen, hall and two bathrooms stacked on the right. The plan ships with a 3D fly-through.
Floor plan and 3D preview
- Rooms
- 7
- Floors
- 1
- Total room area
- 134.6 m² (1449 sq ft)
- Outer size
- 13.20 × 10.20 m (43′ 4″ × 33′ 6″)
- Doors and windows
- 5 doors · 6 windows
- Furniture items
- 26
Opens your own copy in the editor; the template itself never changes.
Layout overview
The plan measures 13.20 × 10.20 m (43′ 4″ × 33′ 6″) to the wall center lines, with the living room at the back and the two-bedroom wing to the left. The kitchen, hall, toilet and bath stack down the right side; the front door lands in the hall.
Rooms and dimensions
| Room | Width × length | m² | sq ft |
|---|---|---|---|
| Living room | 9.00 × 6.00 m (29′ 6″ × 19′ 8″) | 54.0 | 581 |
| Bedroom 2 | 4.20 × 6.00 m (13′ 9″ × 19′ 8″) | 25.2 | 271 |
| Bedroom | 4.20 × 4.20 m (13′ 9″ × 13′ 9″) | 17.6 | 190 |
| Kitchen | 4.80 × 2.40 m (15′ 9″ × 7′ 10″) | 11.5 | 124 |
| Hall | 4.20 × 2.40 m (13′ 9″ × 7′ 10″) | 10.1 | 109 |
| Toilet | 4.80 × 1.80 m (15′ 9″ × 5′ 11″) | 8.6 | 93 |
| Bath | 4.20 × 1.80 m (13′ 9″ × 5′ 11″) | 7.6 | 81 |
| Total | 134.6 | 1449 |
Sizes and areas are measured to the center lines of the walls, the same way the editor’s area schedule measures them, so each room’s clear floor is slightly smaller.
What makes this layout work
Living behind the L
The 54.0 m² (581 sq ft) living room and the dining space run along the back wall, with two windows on it.
The bedrooms on the wing
The 17.6 m² (190 sq ft) bedroom and the 25.2 m² (271 sq ft) second bedroom take the left wing and the back right corner.
Two separate wet rooms
The toilet and the bath are separate rooms down the right side, each with its own door off the hall or kitchen.
Furniture in the plan
- ChairLibrary size 0.48 × 0.50 m (1′ 7″ × 1′ 8″)× 4
- NightstandLibrary size 0.45 × 0.40 m (1′ 6″ × 1′ 4″)× 4
- Double bedLibrary size 1.60 × 2.00 m (5′ 3″ × 6′ 7″)× 2
- ShowerLibrary size 0.90 × 0.90 m (2′ 11″ × 2′ 11″)× 2
- SinkLibrary size 0.70 × 0.45 m (2′ 4″ × 1′ 6″)× 2
- ToiletLibrary size 0.40 × 0.70 m (1′ 4″ × 2′ 4″)× 2
- ArmchairLibrary size 0.85 × 0.85 m (2′ 9″ × 2′ 9″)× 1
- Coffee tableLibrary size 1.10 × 0.60 m (3′ 7″ × 2′)× 1
- CounterLibrary size 1.80 × 0.60 m (5′ 11″ × 2′)× 1
- Dining tableLibrary size 1.60 × 0.90 m (5′ 3″ × 2′ 11″)× 1
- FridgeLibrary size 0.70 × 0.70 m (2′ 4″ × 2′ 4″)× 1
- RugLibrary size 2.00 × 1.40 m (6′ 7″ × 4′ 7″)× 1
- SofaLibrary size 2.10 × 0.90 m (6′ 11″ × 2′ 11″)× 1
- StoveLibrary size 0.60 × 0.60 m (2′ × 2′)× 1
- TV standLibrary size 1.60 × 0.45 m (5′ 3″ × 1′ 6″)× 1
- WardrobeLibrary size 1.20 × 0.60 m (3′ 11″ × 2′)× 1
Every item comes from the editor’s furniture library. Select one to move, rotate or resize it to match your own furniture.
Who this template suits
A site with an L-shaped plot
The outline fits an L-shaped or corner plot with setbacks on two sides.
Private bedrooms
The wing layout keeps the bedrooms away from the living and the road side.
A compact house
Seven rooms in an L, keeping the footprint tight.
Things to consider
The hall is on the road side
The 4.20 × 2.40 m (13′ 9″ × 7′ 10″) hall takes the front door, so the entrance is on the street-facing corner.
The living room has two rooms behind it
The living room opens to the kitchen and to the bedroom; add a door if you want the bedroom more private.
The two wet rooms are not en-suites
Both the toilet and the bath open off the hall or kitchen, not the bedrooms. If you want a bath by the bedrooms, rework the right-side stack when you adapt the plan.
Make it fit your space
Open the living into the kitchen
Widen the opening between the living room and the kitchen (the archway) for a more open plan.
Add a bathroom
Split one of the two wet rooms, or draw a new one off the hall (R) with a toilet and basin (D).
Adjust the tour
Reorder the four saved 3D cameras to match the way you want to walk a visitor through the plan.
Frequently asked questions
What rooms are in the L-shaped house?
7 rooms: Living room, Bedroom 2, Bedroom, Kitchen, Hall, Toilet, Bath.
How big is the L-shaped plan?
134.6 m² (1449 sq ft) on one level, to the wall center lines of 13.20 × 10.20 m (43′ 4″ × 33′ 6″).
How many bathrooms?
Two: the toilet and the bath, each its own room off the hall or kitchen.
How does it differ from the other house templates?
The L outline suits a corner plot and keeps the bedrooms on a wing away from the road. Use the 5-room template for a simple rectangle, or the two-storey one for more space on one footprint.
